Home /Products/Screw Air Compressor/Screw Air Compressor High Pressure Air Compressor Machine Portable Air Compressor Screw

Screw Air Compressor High Pressure Air Compressor Machine Portable Air Compressor Screw

1Set/Sets per Month
MOQ
negotiable
Price
Screw Air Compressor High Pressure Air Compressor Machine Portable Air Compressor Screw
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Air Compressor Machine
Type: Screw Air Compressor
Power Source: Diesel
Engine: CUMMINS
Motor Power: 410KW
Working Pressure: 25bar, 34bar
Air Consumption: 31-29m²/min 36.5-32m²/min
Max Working/idle Speed: 1600/1400rpm 1830/1400rpm
Lubricating Oil Capacity: 120L
Fuel Tank Capacity: 700L
Total Displacement: 13L
Application: Water Well Drilling,mining Blasting
Cooling Method: Air Or Water Cooled
Feature: High Drilling Efficiency,Competitive Price
Configuration: Stationary
Warranty: 1 Year
Cylinder No: 6
Dimension(l*w*h): 4100x1800x2050mm
Weight: 5600kg
Highlight:

High Pressure Screw Air Compressor

,

Machine Screw Air Compressor

,

Portable Screw Air Compressor
Basic Infomation
Place of Origin: Zhejiang, China
Brand Name: SANROCK
Certification: CE ISO 9001:2015
Model Number: QSDS1320LG-34
Payment & Shipping Terms
Packaging Details: Nude package for machines, Wooden box package for spare parts, Or customer demand.
Delivery Time: 15-30days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 300Set/Sets per Month
Product Description


Screw Air Compressor High Pressure Air Compressor Machine Portable Air Compressor Screw 0Screw Air Compressor High Pressure Air Compressor Machine Portable Air Compressor Screw 1

Screw Air Compressor High Pressure Air Compressor Machine Portable Air Compressor Screw 2

Screw Air Compressor High Pressure Air Compressor Machine Portable Air Compressor Screw 3

1.This series primarily used with water well and geothermal project required 115-254mm drill rigs and various other air source requirement.
2.To add to the benefits of the portable compressors,this series specially good for continues running and with transportation requirement in consideration,upgraded for better durability and lower fuel consumption.
Feature:
1.The QSDS1320LG-34 screw air compressor is designed for high efficiency and high performance. It utilizes screw technology to deliver a high volume of compressed air with minimal energy consumption. 2.It can handle heavy-duty tasks and provide a continuous supply of compressed air, allowing for seamless operation in demanding environments.
3.The QSDS1320LG-34 is equipped with an control system that offers precise control over the compressor's operation. The control system enables accurate monitoring of pressure levels, temperature, and other parameters, ensuring optimal performance and safety.
4.The QSDS1320LG-34 is designed for easy maintenance and serviceability. It features accessible maintenance points and user-friendly components, simplifying routine inspections, oil changes, and filter replacements.
Screw Air Compressor High Pressure Air Compressor Machine Portable Air Compressor Screw 4
Screw Air Compressor High Pressure Air Compressor Machine Portable Air Compressor Screw 5Screw Air Compressor High Pressure Air Compressor Machine Portable Air Compressor Screw 6

Screw Air Compressor High Pressure Air Compressor Machine Portable Air Compressor Screw

Products Description

Product name
Screw air compressor
Brand Name
Sanrock
Model Number
QSDS1320LG-34
Compressor
Pressure (bar)
21-25 21-34
Air consumption (m²/min)
31-29 36.5-32
Lubricating oil capacity(L)
120
Dual transformation
Dual
Engine
brand
Cummins
Mode
QSZ 13-C550
Power (kw)
410
Max working/idle speed (rpm
1600/1400 1830/1400
Cylinder No
6
Total displacement(L)
13
Emission standard
Stage Ⅲ
Fuel tank capacity (L)
700
Unit
xhaust port specifications *Quant
G2*1&G3/4*1
Wheel specifications *Quantity
Skid mounted
Noise[Db(A)]
85±3
Dimension (mm
4100x1800x2050
Weight (kg)
5600





Screw Air Compressor High Pressure Air Compressor Machine Portable Air Compressor Screw 7

Screw Air Compressor High Pressure Air Compressor Machine Portable Air Compressor Screw 8



Screw Air Compressor High Pressure Air Compressor Machine Portable Air Compressor Screw 9

Screw Air Compressor High Pressure Air Compressor Machine Portable Air Compressor Screw 10

Screw Air Compressor High Pressure Air Compressor Machine Portable Air Compressor Screw 11Screw Air Compressor High Pressure Air Compressor Machine Portable Air Compressor Screw 12

Screw Air Compressor High Pressure Air Compressor Machine Portable Air Compressor Screw 13

Company Profile

Screw Air Compressor High Pressure Air Compressor Machine Portable Air Compressor Screw 14

Screw Air Compressor High Pressure Air Compressor Machine Portable Air Compressor Screw 15

Screw Air Compressor High Pressure Air Compressor Machine Portable Air Compressor Screw 16

1.What can you buy from us?

DTH drilling rig,Integrated DTH DTH drilling rig ,core drilling rig,highway pile driver,solar pile driver ,anchor pile driver,rotary drill rig ,Top Hammer drill rig,Underground jumbo drill rig ,DTH hammer,drill rod,screw air compressor,screw air compressor,piston air compressor,pneumatic rock drill ,drill bit,tricone bit ,spare parts.



2.How can I make payment?

A:You can pay by credit card, TT, Western Union, LC etc.



3. How is the shipment? How long dose it take?

A: For large quantity or heavy products, we ship by sea shipping or land shipping. Shipping efficiency depends on country and city you want to ship to. For small and delicate products, we ship by DHL, UPS, Fedex or TNT.You can also appoint shipping method you like before we ship.



4.How is your quality control?

A: We have our own experienced QC.There will be strict inspection and testing for every order before shipping out.
