Rotary Drilling Rig Hydraulic Pile Foundation Machinery Rotary Borehole Drilling Machine

1Set/Sets per Month
MOQ
negotiable
Price
Rotary Drilling Rig Hydraulic Pile Foundation Machinery Rotary Borehole Drilling Machine
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Rotary Drilling Rig Machine
Type: Rotary Drilling Rig
Name: Hydraulic Drilling Rig
Power Type: Diesel
Power(w): 153KW
Drilling Diameter: 1400mm
Drilling Depth: 25m
Rotate Speed: 17-35r/min
Max.pull-down Piston Push: 100KN
Max.pull-down Piston Pull: 120KN
Working Pressure: 32Mpa
Maximum Stroke: 3000mm
Walking Speed: 2.5kw/h
Usage: Construction,Piling Foundation
Application: Pile Foundation,Blasthole Drilling,Construction Works,foundation Engineering
Warranty: 1 Year
Dimension(l*w*h): 7150*2600*13100mm
Weight: 26000 KG
Highlight:

Hydraulic Pile Foundation Machinery

,

Borehole Rotary Drilling Rig

,

Rotary Borehole Drilling Machine

Basic Infomation
Place of Origin: Zhejiang, China
Brand Name: SANROCK
Certification: CE ISO 9001:2015
Model Number: SRP525
Payment & Shipping Terms
Packaging Details: Nude package for machines, Wooden box package for spare parts, Or customer demand.
Delivery Time: 30days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 300Set/Sets per Month
Product Description



Rotary Drilling Rig Hydraulic Pile Foundation Machinery Rotary Borehole Drilling Machine 0



Rotary Drilling Rig Hydraulic Pile Foundation Machinery Rotary Borehole Drilling Machine 1Rotary Drilling Rig Hydraulic Pile Foundation Machinery Rotary Borehole Drilling Machine 2Rotary Drilling Rig Hydraulic Pile Foundation Machinery Rotary Borehole Drilling Machine 3

Rotary Drilling Rig Hydraulic Pile Foundation Machinery Rotary Borehole Drilling Machine 4

The streamlined design of the whole machine is fashionable and elegant, efficient operation, stable performance, and high-cost performance.
Equipped with a high-definition operation screen, drill pipe verticality can be adjusted freely in the cab.
The power head has a large torque, and the gear speed can be changed according to different geologic humanizations by adopting three gears: high, middle, and low gears.
Automated depth detection, and control drilling degree at any time.

Rotary Drilling Rig Hydraulic Pile Foundation Machinery Rotary Borehole Drilling Machine 5

Rotary Drilling Rig Hydraulic Pile Foundation Machinery Rotary Borehole Drilling Machine 6

Products Description

Produce Name: Rotary Drilling Rig
SRP525 hydraulic rotary drilling machine
Engine
Model
6105ZIY4/YC
Rated power
KW
153
Rotary Drive
Max.output torque
KN.m
100
Rotary speed
r/min
17-35
Max.Drilling Diameter
mm
1400
Max.Drilling Depth
m
25
Main Winch
Rated Tension
KN
80
Max.single-rope speed
m/min
60
Auxiliary Winch
Rated Tension
KN
30
Max.single-rope speed
m/min
60
Lateral/forward/backward inclination of mast
°
±5/5/15
Pull-Down Cylinder
Max.pull-down piston push
KN
100
Max.pull-down piston pull
KN
120
Maximum stroke
mm
3000
Chassis
Max.traveling speed
km/h
2.5
Min.ground claerance
mm
360
Crawler board width
mm
600
System Working Pressure

MPa
32
Overall Drilling Weight

t
26
Dimension
Working Condition
mm
7150*2600*13100
Transportation Condition
mm
11100*2600*3450

Rotary Drilling Rig Hydraulic Pile Foundation Machinery Rotary Borehole Drilling Machine 7



Rotary Drilling Rig Hydraulic Pile Foundation Machinery Rotary Borehole Drilling Machine 8

Rotary Drilling Rig Hydraulic Pile Foundation Machinery Rotary Borehole Drilling Machine 9

Rotary Drilling Rig Hydraulic Pile Foundation Machinery Rotary Borehole Drilling Machine 10Rotary Drilling Rig Hydraulic Pile Foundation Machinery Rotary Borehole Drilling Machine 11

Rotary Drilling Rig Hydraulic Pile Foundation Machinery Rotary Borehole Drilling Machine 12

Company Profile

Rotary Drilling Rig Hydraulic Pile Foundation Machinery Rotary Borehole Drilling Machine 13

Rotary Drilling Rig Hydraulic Pile Foundation Machinery Rotary Borehole Drilling Machine 14

Rotary Drilling Rig Hydraulic Pile Foundation Machinery Rotary Borehole Drilling Machine 15

1.What can you buy from us?

DTH drilling rig,Integrated DTH DTH drilling rig ,core drilling rig,highway pile driver,solar pile driver ,anchor pile driver,rotary drill rig ,Top Hammer drill rig,Underground jumbo drill rig ,DTH hammer,drill rod,screw air compressor,screw air compressor,piston air compressor,pneumatic rock drill ,drill bit,PDC drill bit,top hammer drill bit,tricone bit ,spare parts.


2.How can I make payment?

A:You can pay by credit card, TT, Western Union, LC etc.




3.How is the shipment? How long dose it take?

A: For large quantity or heavy products, we ship by sea shipping or land shipping. Shipping efficiency depends on country and city you want to ship to. For small and delicate products, we ship by DHL, UPS, Fedex or TNT. You can also appoint shipping method you like before we ship.




4.How is your quality control?
A: We have our own experienced QC. There will be strict inspection and testing for every order before shipping out.
