18m3/min Air Consumption Mobile Screw Air Compressor for Mining

1Set/Sets per Month
MOQ
negotiable
Price
18m3/min Air Consumption Mobile Screw Air Compressor for Mining
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Screw Air Compressor,Air Compressor Machine
Name: Rotary Screw Air Compressor
Cooling Method: Air Or Water Cooled
Diesel Engine: Yuchai
Motor Power: 191KW
Air Consumption: 18m³/min
Working Pressure: 20bar
Fuel Tank Capacity: 340L
Max Working/Idle Speed: 1750/1300rpm
Application: Water Well Drilling,mining Blasting,General Industry,Air
Feature: High Drilling Efficiency,Competitive Price
Configuration: Portable
Outlet Valve: 1*G1 1/2 & 1*G3/4
Dime3200*1800*2100mmnsion(l*w*h): 4450*2120*2142mm
Weight: 2800 KG
Warranty: 1 Year
Type: 2wheel
Noise: 82±3dB(A)
Emission Standard: Stage Ⅲ
Core Components: PLC, Pressure Vessel, Engine, Motor, Pump, Gearbox
Graphic Customization: Min. Order: 1
Color: Customize
Highlight:

18m3/min Rotary Screw Air Compressor

,

Mining Screw Air Compressor

,

18m3/min Screw Air Compressor

Basic Infomation
Place of Origin: Zhejiang, China
Brand Name: SANROCK
Certification: CE ISO 9001:2015
Model Number: QSDP660LG-20C
Payment & Shipping Terms
Packaging Details: Nude package for machines, Wooden box package for spare parts, Or customer demand.
Delivery Time: 15-30days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5000Set/Sets per Month
Product Description





18m3/min Air Consumption Mobile Screw Air Compressor for Mining 018m3/min Air Consumption Mobile Screw Air Compressor for Mining 1

This series primarily used with construction and mining ,bolting rig, various hand held drill machines, drifters, blasting equipment and various air source requirement.

Features:
1.The host has higher efficiency, better reliability and longer life.
2.The diesel engine has strong power and low fuel consumption.
3.The air volume control system is simple and reliable, saving diesel.
4.Multi-stage air filter, suitable for dusty working environment.
5.Easy to move, it can still move flexibly in harsh terrain conditions.
6.long lifetime and low maintenaince cost.

18m3/min Air Consumption Mobile Screw Air Compressor for Mining 218m3/min Air Consumption Mobile Screw Air Compressor for Mining 318m3/min Air Consumption Mobile Screw Air Compressor for Mining 4



18m3/min Air Consumption Mobile Screw Air Compressor for Mining 518m3/min Air Consumption Mobile Screw Air Compressor for Mining 6





18m3/min Air Consumption Mobile Screw Air Compressor for Mining 7



18m3/min Air Consumption Mobile Screw Air Compressor for Mining 8

Products Description

Configuration
PORTABLE
Power
191kw
Brand Name
SANROCK
Model Number
QSDP660LG-20C
Dimension(L*W*H)
4450*2120*2142mm
Weight
2800kg
Emission Standard
Stage Ⅲ
Working Pressure
20bar
Max Working/Idle Speed
1750/1300rpm
Product name
Screw Air Compressor
Application
mining quarry, water well,constructure,etc
Keywords
Air Compressor Screw
Feature
High Efficiency
Capacity
18m3/min
Fuel tank capacity
340L
Noise
82±3dB(A)
Type
2wheel
Outlet Valve
1*G1 1/2 & 1*G3/4
Diesel engine
Yuchai
Cooling method
Air Cooling



18m3/min Air Consumption Mobile Screw Air Compressor for Mining 9

18m3/min Air Consumption Mobile Screw Air Compressor for Mining 10

18m3/min Air Consumption Mobile Screw Air Compressor for Mining 11

18m3/min Air Consumption Mobile Screw Air Compressor for Mining 12

18m3/min Air Consumption Mobile Screw Air Compressor for Mining 13



18m3/min Air Consumption Mobile Screw Air Compressor for Mining 1418m3/min Air Consumption Mobile Screw Air Compressor for Mining 15





18m3/min Air Consumption Mobile Screw Air Compressor for Mining 16



Company Profile

18m3/min Air Consumption Mobile Screw Air Compressor for Mining 17

18m3/min Air Consumption Mobile Screw Air Compressor for Mining 18

18m3/min Air Consumption Mobile Screw Air Compressor for Mining 19

1.What can you buy from us?

DTH drilling rig,core drilling rig,highway pile driver,solar pile driver ,anchor pile driver,rotary drill rig ,Top Hammer drill rig,underground jumbo drill rig ,hydraulic scaling rig,DTH hammer,drill rod,screw air compressor,water well drilling rig,truck mounted water well drilling rig,reverse circulation drilling rig,environmental drilling rig,screw air compressor,piston air compressor,pneumatic rock drill ,drill bit,tricone bit ,spare parts.



2.How can I make payment?

A:You can pay by credit card, TT, Western Union, LC etc.



3. How is the shipment? How long dose it take?

A: For large quantity or heavy products, we ship by sea shipping or land shipping. Shipping efficiency depends on country and city you want to ship to. For small and delicate products, we ship by DHL, UPS, Fedex or TNT.You can also appoint shipping method you like before we ship.



4.How is your quality control? A: We have our own experienced QC.There will be strict inspection and testing for every order before shipping out.
