Mining High Pressure Air Compressor Screw Direct Driven Mobile Air Compressor Machine

1Set/Sets per Month
MOQ
negotiable
Price
Mining High Pressure Air Compressor Screw Direct Driven Mobile Air Compressor Machine
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Screw Air Compressor,Mining Air Compressor
Name: Air Compressor Machine
Cooling Method: Air Or Water Cooled
Motor Power: 240KW
ENGINE: Cummins
Rated Operating Pressure: 10.3(150)bar(psi)
Operating Pressure Range: 3.8-10.3(55-150)bar(psi)
Rated Speed: 1850/1300rpm
Maximum Working Altitude: 3048m
Application: Water Well Drilling,mining Blasting,General Industry,Air
Feature: High Drilling Efficiency,Competitive Price
Configuration: Portable
Cooling: Air Or Water Cooled
Outlet Valve: 1*G1 1/2 & 1*G3/4
Dime3200*1800*2100mmnsion(l*w*h): 3700x1900x2400mmmm
Weight: 4500 KG
Warranty: 1 Year
Core Components: PLC, Pressure Vessel, Engine, Gear, Motor, Bearing, Gearbox
Highlight:

Screw Direct Driven Mobile Air Compressor

Basic Infomation
Place of Origin: Zhejiang, China
Brand Name: SANROCK
Certification: CE ISO 9001:2015
Model Number: QSDP900SV-150
Payment & Shipping Terms
Packaging Details: Nude package for machines, Wooden box package for spare parts, Or customer demand.
Delivery Time: 15-30days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5000Set/Sets per Month
Product Description

Mining High Pressure Air Compressor Screw Direct Driven Mobile Air Compressor Machine 0Mining High Pressure Air Compressor Screw Direct Driven Mobile Air Compressor Machine 1

Mining High Pressure Air Compressor Screw Direct Driven Mobile Air Compressor Machine 2Mining High Pressure Air Compressor Screw Direct Driven Mobile Air Compressor Machine 3

Feature:
1.Cummins Engine.
2.Energy Efficient Twin Screw Rotor Air Ends for Stable and Continuous Air Supply.
3.Highly Flexible Coupling Between Rotors and Engine for Improved Reliability.
4.Air End Manufactured by Sullivan-Palatek Comes With an Exclusive Three Three-year Warranty.
5.Automatic 0% to 100% Capacity Control.
6.Ambient Opretion Tempreture Range:-4°to+122°F(-20°to+50 ℃).
7.Air Oil Separator With Wave Shaping Technology Ensures Highest Quality Discharge.
8.No High Wear Parts, Reducing Cost of Maintenance.
9.Energy Efficient Inlet Valve Mechanism.
10.Sound Deadening Material Ensures Quiet Operation.
11.Large Service Doors for Ease of Maintenance and Repair.

This series primarily used with construction and mining ,bolting rig, various hand held drill machines, drifters, blasting equipment and various air source requirement.



Mining High Pressure Air Compressor Screw Direct Driven Mobile Air Compressor Machine 4

Mining High Pressure Air Compressor Screw Direct Driven Mobile Air Compressor Machine 5

Mining High Pressure Air Compressor Screw Direct Driven Mobile Air Compressor Machine 6Mining High Pressure Air Compressor Screw Direct Driven Mobile Air Compressor Machine 7



Mining High Pressure Air Compressor Screw Direct Driven Mobile Air Compressor Machine 8

Products Description

Product name
air compressor
Compressor Model
QSDP900SV-150
Rated Delivery
CFM(m3/min)
900(25.5)
Rated Operating Pressure
bar(psi)
10.3(150)
Operating Pressure Range
bar(psi)
3.8-10.3(55-150)
Stages of Compression

1
Dimensions
mm
3700x1900x2400
Estimated Weight, Serviced
kg
4500
Noise Level
db(A)
80±3
Max. WorkingAngle
º
15
Lubricant Capacity
L(gal)
85(22.5)
Air Discharge Outlet
inch
1-NPT2,1-NPT3/4
Maximum working altitude
m
3048
ENGINE

Cummins (DCEC)

Model

6LTAA8.9-C325
Rated Power
kW(Hp)
240(325)
Rated Speed (Load/ldle)
rpm
1850/1300
Displacement
L(in3)
8.9(543)
Fuel Tank Capacity
L(gal)
700(185)
OperatingVoltage for Electrical System
DC-V
24
Rated Capactiy of Battery
A.H
165x2

Mining High Pressure Air Compressor Screw Direct Driven Mobile Air Compressor Machine 9

Mining High Pressure Air Compressor Screw Direct Driven Mobile Air Compressor Machine 10

Mining High Pressure Air Compressor Screw Direct Driven Mobile Air Compressor Machine 11

Mining High Pressure Air Compressor Screw Direct Driven Mobile Air Compressor Machine 12

Mining High Pressure Air Compressor Screw Direct Driven Mobile Air Compressor Machine 13



Mining High Pressure Air Compressor Screw Direct Driven Mobile Air Compressor Machine 14Mining High Pressure Air Compressor Screw Direct Driven Mobile Air Compressor Machine 15





Mining High Pressure Air Compressor Screw Direct Driven Mobile Air Compressor Machine 16



Company Profile

Mining High Pressure Air Compressor Screw Direct Driven Mobile Air Compressor Machine 17

Mining High Pressure Air Compressor Screw Direct Driven Mobile Air Compressor Machine 18

Mining High Pressure Air Compressor Screw Direct Driven Mobile Air Compressor Machine 19

1.What can you buy from us?

DTH drilling rig,core drilling rig,highway pile driver,solar pile driver ,anchor pile driver,rotary drill rig ,Top Hammer drill rig,underground jumbo drill rig ,hydraulic scaling rig,DTH hammer,drill rod,screw air compressor,water well drilling rig,truck mounted water well drilling rig,reverse circulation drilling rig,environmental drilling rig,screw air compressor,piston air compressor,pneumatic rock drill ,drill bit,tricone bit ,spare parts.



2.How can I make payment?

A:You can pay by credit card, TT, Western Union, LC etc.



3. How is the shipment? How long dose it take?

A: For large quantity or heavy products, we ship by sea shipping or land shipping. Shipping efficiency depends on country and city you want to ship to. For small and delicate products, we ship by DHL, UPS, Fedex or TNT.You can also appoint shipping method you like before we ship.



4.How is your quality control? A: We have our own experienced QC.There will be strict inspection and testing for every order before shipping out.
