Pneumatic Rock Drill Concrete Breaker Jack Hammer Portable Rock Drilling Machine

1Set/Sets per Month
MOQ
negotiable
Price
Pneumatic Rock Drill Concrete Breaker Jack Hammer Portable Rock Drilling Machine
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Jack Hammer
Name: Pneumatic Rock Drill
Type: Rotary Drilling Rig
Feature: High Drilling Efficiency,Hydraulic Controlling,Portable
Application: Quarry, Mining, Road Construction,concrete Breaking
Drilling Diameter: 50-57mm
Drilling Depth: 6m
Impact Frequency: ≥33 Hz
Air Consumption: ≤33 L/S
Air Pressur: 0.4-0.63 Mpa
Cylinder Diameter: 65mm
Weight: 20.5 KG
Key Selling Points: Easy To Operate
Highlight:

Portable Rock Drilling Machine

,

Concrete Breaker Jack Hammer

,

Pneumatic Rock Drill

Basic Infomation
Place of Origin: Zhejiang, China
Brand Name: SANROCK
Certification: CE ISO 9001:2015
Model Number: Y20
Payment & Shipping Terms
Packaging Details: Nude package for machines, Wooden box package for spare parts, Or customer demand.
Delivery Time: 15days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5000Set/Sets per Month
Product Description

We offer a range of hand drills,leg drills and feed drilld.It is mainly used for blasting holed and other drilling works railway construction,water conservancy construction and defence project facility.It is suitable for drilling and blasting under various of rocks at any direction angles.

This Series pneumatic rock drill apply in hard rock on the rock drill operation,it has strong adaptability to the working conditions.The product is energy efficiency, Its components has long life and durable.The machice can be generally used with the same type,it can greatly reduce the customer loss for spare part replacement.

Pneumatic Rock Drill Concrete Breaker Jack Hammer Portable Rock Drilling Machine 0Pneumatic Rock Drill Concrete Breaker Jack Hammer Portable Rock Drilling Machine 1
Pneumatic Rock Drill Concrete Breaker Jack Hammer Portable Rock Drilling Machine 2



1.Original in distributing construction, nimble in starting, and smooth in operation.
2.low noise, spare parts easily purchasing ,parts highly interchangeable and reliable performance.
3. Can be used on all rock formation, fast drilling velocity and energy-saving with low vibration and low noise.
4. Energy-saving and efficient, long service life of parts, adn the parts are highly interchangeable and reliable preformance.
5.Grouped control machanism, quick to start up, with "air on, water on, air off, water off" machanism, convenient to handle an deasy to maintain and repair.

Pneumatic Rock Drill Concrete Breaker Jack Hammer Portable Rock Drilling Machine 3

Pneumatic Rock Drill Concrete Breaker Jack Hammer Portable Rock Drilling Machine 4



Pneumatic Rock Drill Concrete Breaker Jack Hammer Portable Rock Drilling Machine 5



Products Description

Product name: pneumatic rock drill
Name:Y20 jack hammer
Working pressure:0.4-0.63Mpa
Impact frequency:≥33Hz
Impact energy:≥26J
Cylinder Diameter:65mm
Air consumption:≤33(L/S)
Drilling Depth:6m
Piston Stroke:55mm
Weight:20.5kg
Use:mining, coal mining, engineering construction
Feature:Easy Operation

Pneumatic Rock Drill Concrete Breaker Jack Hammer Portable Rock Drilling Machine 6Pneumatic Rock Drill Concrete Breaker Jack Hammer Portable Rock Drilling Machine 7

Pneumatic Rock Drill Concrete Breaker Jack Hammer Portable Rock Drilling Machine 8Pneumatic Rock Drill Concrete Breaker Jack Hammer Portable Rock Drilling Machine 9

Pneumatic Rock Drill Concrete Breaker Jack Hammer Portable Rock Drilling Machine 10

Pneumatic Rock Drill Concrete Breaker Jack Hammer Portable Rock Drilling Machine 11Pneumatic Rock Drill Concrete Breaker Jack Hammer Portable Rock Drilling Machine 12

Pneumatic Rock Drill Concrete Breaker Jack Hammer Portable Rock Drilling Machine 13

Pneumatic Rock Drill Concrete Breaker Jack Hammer Portable Rock Drilling Machine 14
