High Drilling Efficiency Pneumatic Rock Drill for Construction Works Air Leg Jack Hammer

1Set/Sets per Month
MOQ
negotiable
Price
High Drilling Efficiency Pneumatic Rock Drill for Construction Works Air Leg Jack Hammer
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Jack Hammer
Name: Pneumatic Rock Drill
Type: Rotary Drilling Rig
Feature: High Drilling Efficiency,Hydraulic Controlling,Portable
Application: Quarry, Mining, Road Construction,concrete Breaking
Drilling Diameter: 50-57mm
Drilling Depth: 6m
Impact Frequency: ≥33 Hz
Air Consumption: ≤33 L/S
Air Pressur: 0.4-0.63 Mpa
Cylinder Diameter: 65mm
Weight: 20.5 KG
Key Selling Points: Easy To Operate
Highlight:

Construction Works Rock Drill

,

Air Leg Jack Hammer Rock Drill

,

High Drilling Efficiency Rock Drill

Basic Infomation
Place of Origin: Zhejiang, China
Brand Name: SANROCK
Certification: CE ISO 9001:2015
Model Number: Y20
Payment & Shipping Terms
Packaging Details: Nude package for machines, Wooden box package for spare parts, Or customer demand.
Delivery Time: 15days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5000Set/Sets per Month
Product Description

High Drilling Efficiency Pneumatic Rock Drill for Construction Works Air Leg Jack Hammer 0High Drilling Efficiency Pneumatic Rock Drill for Construction Works Air Leg Jack Hammer 1

High Drilling Efficiency Pneumatic Rock Drill for Construction Works Air Leg Jack Hammer 2

High Drilling Efficiency Pneumatic Rock Drill for Construction Works Air Leg Jack Hammer 3

We offer a range of hand drills,leg drills and feed drilld.It is mainly used for blasting holed and other drilling works railway construction,water conservancy construction and defence project facility.It is suitable for drilling and blasting under various of rocks at any direction angles.

This Series pneumatic rock drill apply in hard rock on the rock drill operation,it has strong adaptability to the working conditions.The product is energy efficiency, Its components has long life and durable.The machice can be generally used with the same type,it can greatly reduce the customer loss for spare part replacement.

High Drilling Efficiency Pneumatic Rock Drill for Construction Works Air Leg Jack Hammer 4High Drilling Efficiency Pneumatic Rock Drill for Construction Works Air Leg Jack Hammer 5




High Drilling Efficiency Pneumatic Rock Drill for Construction Works Air Leg Jack Hammer 6High Drilling Efficiency Pneumatic Rock Drill for Construction Works Air Leg Jack Hammer 7
1.Original in distributing construction, nimble in starting, and smooth in operation.
2.low noise, spare parts easily purchasing ,parts highly interchangeable and reliable performance.
3. Can be used on all rock formation, fast drilling velocity and energy-saving with low vibration and low noise.
4. Energy-saving and efficient, long service life of parts, adn the parts are highly interchangeable and reliable preformance.
5.Grouped control machanism, quick to start up, with "air on, water on, air off, water off" machanism, convenient to handle an deasy to maintain and repair.



High Drilling Efficiency Pneumatic Rock Drill for Construction Works Air Leg Jack Hammer 8



Products Description

Product name: pneumatic rock drill
Name:Y20 jack hammer
Working pressure:0.4-0.63Mpa
Impact frequency:≥33Hz
Impact energy:≥26J
Cylinder Diameter:65mm
Air consumption:≤33(L/S)
Drilling Depth:6m
Piston Stroke:55mm
Weight:20.5kg
Use:mining, coal mining, engineering construction
Feature:Easy Operation

High Drilling Efficiency Pneumatic Rock Drill for Construction Works Air Leg Jack Hammer 9

High Drilling Efficiency Pneumatic Rock Drill for Construction Works Air Leg Jack Hammer 10High Drilling Efficiency Pneumatic Rock Drill for Construction Works Air Leg Jack Hammer 11

High Drilling Efficiency Pneumatic Rock Drill for Construction Works Air Leg Jack Hammer 12High Drilling Efficiency Pneumatic Rock Drill for Construction Works Air Leg Jack Hammer 13

High Drilling Efficiency Pneumatic Rock Drill for Construction Works Air Leg Jack Hammer 14

High Drilling Efficiency Pneumatic Rock Drill for Construction Works Air Leg Jack Hammer 15High Drilling Efficiency Pneumatic Rock Drill for Construction Works Air Leg Jack Hammer 16

High Drilling Efficiency Pneumatic Rock Drill for Construction Works Air Leg Jack Hammer 17

High Drilling Efficiency Pneumatic Rock Drill for Construction Works Air Leg Jack Hammer 18



Company Information

High Drilling Efficiency Pneumatic Rock Drill for Construction Works Air Leg Jack Hammer 19

High Drilling Efficiency Pneumatic Rock Drill for Construction Works Air Leg Jack Hammer 20

High Drilling Efficiency Pneumatic Rock Drill for Construction Works Air Leg Jack Hammer 21

High Drilling Efficiency Pneumatic Rock Drill for Construction Works Air Leg Jack Hammer 22

1.What can you buy from us?
DTH drilling rig,core drilling rig,highway pile driver,solar pile driver ,anchor pile driver,rotary drill rig ,Top Hammer drill rig,underground jumbo drill rig ,DTH hammer,drill rod,screw air compressor,water well drilling rig,truck mounted water well drilling rig,screw air compressor,piston air compressor,pneumatic rock drill ,drill bit,tricone bit ,spare parts.



2.How can I make payment?
A:You can pay by credit card, TT, Western Union, LC etc.



3.How is the shipment? How long dose it take?
A: For large quantity or heavy products, we ship by sea shipping or land shipping. Shipping efficiency depends on country and city you want to ship to. For small and delicate products, we ship by DHL, UPS, Fedex or TNT. You can also appoint shipping method you like before we ship.



4.How is your quality control?
A: We have our own experienced QC. There will be strict inspection and testing for every order before shipping out.
