650 x 240 x 202mm Air Leg Rock Drill Machine Portable Jack Hammer for Construction Works

1Set/Sets per Month
MOQ
negotiable
Price
650 x 240 x 202mm Air Leg Rock Drill Machine Portable Jack Hammer for Construction Works
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Jack Hammer
Name: Portable Pneumatic Rock Drill
Drilling Diameter: 34-42mm
Drilling Depth: 1-6m
Application: Mining ,blast Hole Drilling,metallurgy, Coal,railway, Transportation
Feature: High Drilling Efficiency,High Performance
Working Pressure(bar): 0.4-0.63Mpa
Drill Rod Diameter: Hex 22*108
Impact Energy: ≥30 J
Impact Frequency: ≥23 Hz
Air Consumption: ≤47 L/S
Dimension(L*W*H): 650 X 240 X 202mm
Weight: 26KG
Highlight:

Portable Jack Hammer Rock Drill Machine

,

202mm Air Leg Rock Drill Machine

,

Construction Works Rock Drill Machine

Basic Infomation
Place of Origin: Zhejiang, China
Brand Name: SANROCK
Certification: CE ISO 9001:2015
Model Number: YT26
Payment & Shipping Terms
Packaging Details: Nude package for machines, Wooden box package for spare parts, Or customer demand.
Delivery Time: 15-25days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5000Set/Sets per Month
Product Description

YT26 pneumatic rock drill is an important tool for rock drilling operation in mines, railway, communication and water conservancy projects. Suitable for making horizontal and inclined blast holes in medium-hard and hard rocks.

650 x 240 x 202mm Air Leg Rock Drill Machine Portable Jack Hammer for Construction Works 0

650 x 240 x 202mm Air Leg Rock Drill Machine Portable Jack Hammer for Construction Works 1

650 x 240 x 202mm Air Leg Rock Drill Machine Portable Jack Hammer for Construction Works 2650 x 240 x 202mm Air Leg Rock Drill Machine Portable Jack Hammer for Construction Works 3
Feature:
1.Fit for wet drilling in medium-hard or hard rock.
2.Grouped control mechanism,quick to start up, with "air on ,water on, air off,water off" mechanism,convenient to handle andeasy to maintain and repair.
3.Long service life of parts, parts highly interchangeable and reliable performance.
4.YT26 differ form similar products particularly in its high efficiency, strong flushing and powerful torque.



650 x 240 x 202mm Air Leg Rock Drill Machine Portable Jack Hammer for Construction Works 4

650 x 240 x 202mm Air Leg Rock Drill Machine Portable Jack Hammer for Construction Works 5

650 x 240 x 202mm Air Leg Rock Drill Machine Portable Jack Hammer for Construction Works 6

650 x 240 x 202mm Air Leg Rock Drill Machine Portable Jack Hammer for Construction Works 7



650 x 240 x 202mm Air Leg Rock Drill Machine Portable Jack Hammer for Construction Works 8



Products Description

Product Name:Pneumatic rock drill
Key Selling Points:efficient and low energy consumption
Working Pressure(bar):0.4-0.63Mpa
Drilling Depth:5m
Drilling Diameter:32mm-42mm
Shank size:H22x108mm
Impact Energy: ≥30 J
Impact Frequency: ≥23 Hz
Air Consumption: ≤47 L/S
Air Pipe Inner Diameter: 19 mm
Water Pipe Inner Diameter: 13 mm
Dimension(L*W*H):650 x 240 x 202 mm
Weight:26 KG
Application:mining ,concrete breaking,metallurgy, coal,railway
Feature:easy Operation,light weight, high drilling efficiency

650 x 240 x 202mm Air Leg Rock Drill Machine Portable Jack Hammer for Construction Works 9

650 x 240 x 202mm Air Leg Rock Drill Machine Portable Jack Hammer for Construction Works 10

650 x 240 x 202mm Air Leg Rock Drill Machine Portable Jack Hammer for Construction Works 11650 x 240 x 202mm Air Leg Rock Drill Machine Portable Jack Hammer for Construction Works 12

650 x 240 x 202mm Air Leg Rock Drill Machine Portable Jack Hammer for Construction Works 13650 x 240 x 202mm Air Leg Rock Drill Machine Portable Jack Hammer for Construction Works 14

650 x 240 x 202mm Air Leg Rock Drill Machine Portable Jack Hammer for Construction Works 15

650 x 240 x 202mm Air Leg Rock Drill Machine Portable Jack Hammer for Construction Works 16

650 x 240 x 202mm Air Leg Rock Drill Machine Portable Jack Hammer for Construction Works 17

Company Profile

650 x 240 x 202mm Air Leg Rock Drill Machine Portable Jack Hammer for Construction Works 18

650 x 240 x 202mm Air Leg Rock Drill Machine Portable Jack Hammer for Construction Works 19

650 x 240 x 202mm Air Leg Rock Drill Machine Portable Jack Hammer for Construction Works 20

650 x 240 x 202mm Air Leg Rock Drill Machine Portable Jack Hammer for Construction Works 21

1.What can you buy from us?

DTH drilling rig,Integrated DTH DTH drilling rig ,core drilling rig,highway pile driver,solar pile driver ,anchor pile driver,rotary drill rig ,Top Hammer drill rig,Underground jumbo drill rig ,DTH hammer,screw air compressor,screw air compressor,piston air compressor,pneumatic rock drill ,drill rod,drill bit,PDC drill bit,top hammer drill bit,tricone bit ,spare parts.



2.How can I make payment?

A:You can pay by credit card, TT, Western Union, LC etc.



3.How is the shipment? How long dose it take?

A: For large quantity or heavy products, we ship by sea shipping or land shipping. Shipping efficiency depends on country and city you want to ship to. For small and delicate products, we ship by DHL, UPS, Fedex or TNT. You can also appoint shipping method you like before we ship.


4.How is your quality control?
A: We have our own experienced QC. There will be strict inspection and testing for every order before shipping out.
