Air Leg Pneumatic Rock Drill Portable Jack Hammer YT26 Small Rock Drilling Rig Machine

1Set/Sets per Month
MOQ
negotiable
Price
Air Leg Pneumatic Rock Drill Portable Jack Hammer YT26 Small Rock Drilling Rig Machine
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Jack Hammer
Name: Portable Pneumatic Rock Drill
Drilling Diameter: 34-42mm
Drilling Depth: 1-6m
Application: Mining ,blast Hole Drilling,metallurgy, Coal,railway, Transportation
Feature: High Drilling Efficiency,High Performance
Working Pressure(bar): 0.4-0.63Mpa
Drill Rod Diameter: Hex 22*108
Impact Energy: ≥30 J
Impact Frequency: ≥23 Hz
Air Consumption: ≤47 L/S
Dimension(L*W*H): 650 X 240 X 202mm
Weight: 26KG
Highlight:

Portable Jack Hammer

,

Small Rock Drilling Rig Machine

,

Air Leg Pneumatic Rock Drill

Basic Infomation
Place of Origin: Zhejiang, China
Brand Name: SANROCK
Certification: CE ISO 9001:2015
Model Number: YT26
Payment & Shipping Terms
Packaging Details: Nude package for machines, Wooden box package for spare parts, Or customer demand.
Delivery Time: 15-25days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5000Set/Sets per Month
Product Description

Air Leg Pneumatic Rock Drill Portable Jack Hammer YT26 Small Rock Drilling Rig Machine 0

YT26 pneumatic rock drill is an important tool for rock drilling operation in mines, railway, communication and water conservancy projects. Suitable for making horizontal and inclined blast holes in medium-hard and hard rocks.

Air Leg Pneumatic Rock Drill Portable Jack Hammer YT26 Small Rock Drilling Rig Machine 1

Air Leg Pneumatic Rock Drill Portable Jack Hammer YT26 Small Rock Drilling Rig Machine 2

Feature:
1.Fit for wet drilling in medium-hard or hard rock.
2.Grouped control mechanism,quick to start up, with "air on ,water on, air off,water off" mechanism,convenient to handle andeasy to maintain and repair.
3.Long service life of parts, parts highly interchangeable and reliable performance.
4.YT26 differ form similar products particularly in its high efficiency, strong flushing and powerful torque.

Air Leg Pneumatic Rock Drill Portable Jack Hammer YT26 Small Rock Drilling Rig Machine 3Air Leg Pneumatic Rock Drill Portable Jack Hammer YT26 Small Rock Drilling Rig Machine 4


Air Leg Pneumatic Rock Drill Portable Jack Hammer YT26 Small Rock Drilling Rig Machine 5

Air Leg Pneumatic Rock Drill Portable Jack Hammer YT26 Small Rock Drilling Rig Machine 6

Air Leg Pneumatic Rock Drill Portable Jack Hammer YT26 Small Rock Drilling Rig Machine 7



Air Leg Pneumatic Rock Drill Portable Jack Hammer YT26 Small Rock Drilling Rig Machine 8



Products Description

Product Name:Pneumatic rock drill
Key Selling Points:efficient and low energy consumption
Working Pressure(bar):0.4-0.63Mpa
Drilling Depth:5m
Drilling Diameter:32mm-42mm
Shank size:H22x108mm
Impact Energy: ≥30 J
Impact Frequency: ≥23 Hz
Air Consumption: ≤47 L/S
Air Pipe Inner Diameter: 19 mm
Water Pipe Inner Diameter: 13 mm
Dimension(L*W*H):650 x 240 x 202 mm
Weight:26 KG
Application:mining ,concrete breaking,metallurgy, coal,railway
Feature:easy Operation,light weight, high drilling efficiency



Air Leg Pneumatic Rock Drill Portable Jack Hammer YT26 Small Rock Drilling Rig Machine 9

Air Leg Pneumatic Rock Drill Portable Jack Hammer YT26 Small Rock Drilling Rig Machine 10Air Leg Pneumatic Rock Drill Portable Jack Hammer YT26 Small Rock Drilling Rig Machine 11

Air Leg Pneumatic Rock Drill Portable Jack Hammer YT26 Small Rock Drilling Rig Machine 12Air Leg Pneumatic Rock Drill Portable Jack Hammer YT26 Small Rock Drilling Rig Machine 13

Air Leg Pneumatic Rock Drill Portable Jack Hammer YT26 Small Rock Drilling Rig Machine 14

Air Leg Pneumatic Rock Drill Portable Jack Hammer YT26 Small Rock Drilling Rig Machine 15

Air Leg Pneumatic Rock Drill Portable Jack Hammer YT26 Small Rock Drilling Rig Machine 16

Company Profile

Air Leg Pneumatic Rock Drill Portable Jack Hammer YT26 Small Rock Drilling Rig Machine 17

Air Leg Pneumatic Rock Drill Portable Jack Hammer YT26 Small Rock Drilling Rig Machine 18

Air Leg Pneumatic Rock Drill Portable Jack Hammer YT26 Small Rock Drilling Rig Machine 19

Air Leg Pneumatic Rock Drill Portable Jack Hammer YT26 Small Rock Drilling Rig Machine 20

1.What can you buy from us?

DTH drilling rig,Integrated DTH DTH drilling rig ,core drilling rig,highway pile driver,solar pile driver ,anchor pile driver,rotary drill rig ,Top Hammer drill rig,Underground jumbo drill rig ,DTH hammer,screw air compressor,screw air compressor,piston air compressor,pneumatic rock drill ,drill rod,drill bit,PDC drill bit,top hammer drill bit,tricone bit ,spare parts.



2.How can I make payment?

A:You can pay by credit card, TT, Western Union, LC etc.



3.How is the shipment? How long dose it take?

A: For large quantity or heavy products, we ship by sea shipping or land shipping. Shipping efficiency depends on country and city you want to ship to. For small and delicate products, we ship by DHL, UPS, Fedex or TNT. You can also appoint shipping method you like before we ship.


4.How is your quality control?
A: We have our own experienced QC. There will be strict inspection and testing for every order before shipping out.
