Mining Air Leg Jack Hammer YT28 Concrete Breaking Hand Held Pneumatic Rock Drill

1Set/Sets per Month
MOQ
negotiable
Price
Mining Air Leg Jack Hammer YT28 Concrete Breaking Hand Held Pneumatic Rock Drill
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Jack Hammer
Name: Pneumatic Rock Drill
Keyword: Portable Rock Drilling Machine
Drilling Diameter: 34-56mm
Drilling Depth: 1-6m
Application: Mining,Quarry,construction,blasting,geological Exploration
Feature: High Drilling Efficiency,High Performance
Drill Rod Diameter: Hex 22*108
Working Pressure(bar): 0.4-0.63Mpa
Air Consumption: 4.8m³/min
Cylinder Diameter: 80 Mm
Piston Strock: 60mm
Impacts Frequency: 37 (HZ)
Dimension(L*W*H): 749*310*220mm
Weight: 28KG
Highlight:

Hand Held Air Leg Jack Hammer

,

Concrete Breaking Air Leg Jack Hammer

Basic Infomation
Place of Origin: Zhejiang, China
Brand Name: SANROCK
Certification: CE ISO 9001:2015
Model Number: YT28
Payment & Shipping Terms
Packaging Details: Nude package for machines, Wooden box package for spare parts, Or customer demand.
Delivery Time: 15-25days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5000Set/Sets per Month
Product Description

Mining Air Leg Jack Hammer YT28 Concrete Breaking Hand Held Pneumatic Rock Drill 0

Mining Air Leg Jack Hammer YT28 Concrete Breaking Hand Held Pneumatic Rock Drill 1

Mining Air Leg Jack Hammer YT28 Concrete Breaking Hand Held Pneumatic Rock Drill 2

YT28Rock Drill is used for rock drilling, blasting holes and other drilling works in the quarries, small coal mines and other constructions.
It is suitable for drilling and blasting under various of rocks at any direction angles.This machine could match with short air leg or long air leg.

Feature:
1.Fit for wet drilling in medium-hard or hard rock.
2.Grouped control mechanism,quick to start up, with "air on ,water on, air off,water off" mechanism,convenient to handle andeasy to maintain and repair.
3.Long service life of parts, parts highly interchangeable and reliable performance.
4.YT28differ form similar products particularly in its high efficiency, strong flushing and powerful torque.

Mining Air Leg Jack Hammer YT28 Concrete Breaking Hand Held Pneumatic Rock Drill 3

Mining Air Leg Jack Hammer YT28 Concrete Breaking Hand Held Pneumatic Rock Drill 4

Mining Air Leg Jack Hammer YT28 Concrete Breaking Hand Held Pneumatic Rock Drill 5

Mining Air Leg Jack Hammer YT28 Concrete Breaking Hand Held Pneumatic Rock Drill 6

Mining Air Leg Jack Hammer YT28 Concrete Breaking Hand Held Pneumatic Rock Drill 7





Mining Air Leg Jack Hammer YT28 Concrete Breaking Hand Held Pneumatic Rock Drill 8



Mining Air Leg Jack Hammer YT28 Concrete Breaking Hand Held Pneumatic Rock Drill 9



Products Description

Product name: jack hammer
product model:YT28
impact frequency:≥37HZ
Name: pneumatic rock drill
Impact Energy:>70J
Air Consumption :5m³/min
Air pressure:0.4-0.63Mpa
Maximum drill hole depth:6m
Cylinder Diameter:80 mm
Piston Strock :60mm
Dimension(L*W*H):749*310*220mm
Weight:28kg
Application:mining ,concrete breaking,metallurgy, coal,railway
Feature:easy Operation,light weight, high drilling efficiency

Mining Air Leg Jack Hammer YT28 Concrete Breaking Hand Held Pneumatic Rock Drill 10

Mining Air Leg Jack Hammer YT28 Concrete Breaking Hand Held Pneumatic Rock Drill 11

Mining Air Leg Jack Hammer YT28 Concrete Breaking Hand Held Pneumatic Rock Drill 12Mining Air Leg Jack Hammer YT28 Concrete Breaking Hand Held Pneumatic Rock Drill 13

Mining Air Leg Jack Hammer YT28 Concrete Breaking Hand Held Pneumatic Rock Drill 14

Mining Air Leg Jack Hammer YT28 Concrete Breaking Hand Held Pneumatic Rock Drill 15

Mining Air Leg Jack Hammer YT28 Concrete Breaking Hand Held Pneumatic Rock Drill 16Mining Air Leg Jack Hammer YT28 Concrete Breaking Hand Held Pneumatic Rock Drill 17



Mining Air Leg Jack Hammer YT28 Concrete Breaking Hand Held Pneumatic Rock Drill 18

Mining Air Leg Jack Hammer YT28 Concrete Breaking Hand Held Pneumatic Rock Drill 19

Company Profile

Mining Air Leg Jack Hammer YT28 Concrete Breaking Hand Held Pneumatic Rock Drill 20

Mining Air Leg Jack Hammer YT28 Concrete Breaking Hand Held Pneumatic Rock Drill 21

Mining Air Leg Jack Hammer YT28 Concrete Breaking Hand Held Pneumatic Rock Drill 22

Mining Air Leg Jack Hammer YT28 Concrete Breaking Hand Held Pneumatic Rock Drill 23

1.What can you buy from us?

DTH drilling rig,Integrated DTH DTH drilling rig ,core drilling rig,highway pile driver,solar pile driver ,anchor pile driver,rotary drill rig ,Top Hammer drill rig,Underground jumbo drill rig ,DTH hammer,screw air compressor,screw air compressor,piston air compressor,pneumatic rock drill ,drill rod,drill bit,PDC drill bit,top hammer drill bit,tricone bit ,spare parts.



2.How can I make payment?

A:You can pay by credit card, TT, Western Union, LC etc.



3.How is the shipment? How long dose it take?

A: For large quantity or heavy products, we ship by sea shipping or land shipping. Shipping efficiency depends on country and city you want to ship to. For small and delicate products, we ship by DHL, UPS, Fedex or TNT. You can also appoint shipping method you like before we ship.


4.How is your quality control?
A: We have our own experienced QC. There will be strict inspection and testing for every order before shipping out.
