YT29 YT28 YT27 Rock Drilling Machine Air Leg Jack Hammer Portable Pneumatic Rock Drill

1Set/Sets per Month
MOQ
negotiable
Price
YT29 YT28 YT27 Rock Drilling Machine Air Leg Jack Hammer Portable Pneumatic Rock Drill
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Jack Hammer
Name: Pneumatic Rock Drill
Keyword: Portable Rock Drilling Machine
Drilling Diameter: 34-56mm
Drilling Depth: 1-6m
Application: Quarry, Mining, Construction,concrete Breaking
Feature: High Drilling Efficiency,Hydraulic Controlling,Portable
Cylinder Diameter: 82mm
Drilling Frequency: 37HZ
Impact Energy: >70J
≤65 L/S: ≤65 L/S
Air Pressure: 0.4-0.63mpa
Drill Rod Diameter: Hex 22*108
Dimension(L*W*H): 659*248*205 Mm
Weight: 29KG
Highlight:

Portable Pneumatic Rock Drill

,

Air Leg Jack Hammer

,

YT29 YT28 YT27 Rock Drilling Machine

Basic Infomation
Place of Origin: Zhejiang, China
Brand Name: SANROCK
Certification: CE ISO 9001:2015
Model Number: YT29
Payment & Shipping Terms
Packaging Details: Nude package for machines, Wooden box package for spare parts, Or customer demand.
Delivery Time: 15-25days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5000Set/Sets per Month
Product Description

YT29 YT28 YT27 Rock Drilling Machine Air Leg Jack Hammer Portable Pneumatic Rock Drill 0

YT29 YT28 YT27 Rock Drilling Machine Air Leg Jack Hammer Portable Pneumatic Rock Drill 1

YT29 YT28 YT27 Rock Drilling Machine Air Leg Jack Hammer Portable Pneumatic Rock Drill 2

YT29 YT28 YT27 Rock Drilling Machine Air Leg Jack Hammer Portable Pneumatic Rock Drill 3

Portable Pneumatic Rock Drill :A tool used to extract stone directly by drilling holes in rock formations for explosive charges to blast through the rock to complete the quarrying of stone or other masonry. In addition, the drill can be converted into a destructor, used to break up hard layers such as concrete.

Usage: mining and construction work - the application scope includes construction demolition operation, geological exploration drilling and foundation engineering, as well as cement road surface, asphalt road surface of all kinds of splitting, crushing,tamping, shovel and fire rescue functions, more suitable for all kinds of mining drilling, splitting, mining. And with good performance, high efficiency, light weight, easy to use and other advantages.

YT29 YT28 YT27 Rock Drilling Machine Air Leg Jack Hammer Portable Pneumatic Rock Drill 4

YT29 YT28 YT27 Rock Drilling Machine Air Leg Jack Hammer Portable Pneumatic Rock Drill 5

YT29 YT28 YT27 Rock Drilling Machine Air Leg Jack Hammer Portable Pneumatic Rock Drill 6

Features:
1, Portable Handheld Pneumatic Air Leg Rock Drill is fit for wet drilling in medium-hard or hard rock.
2, Grouped control mechanism, quick to start up, with "air on ,water on, air off, water off" mechanism, convenient to handle and easy to maintain and repair.
3, Energy-saving and efficient, long service life of parts, parts highly interchangeable and reliable performance.
4. Can play a variety of small diameter and shallow hole. Generally only downward holes and nearly horizontal holes.

YT29 YT28 YT27 Rock Drilling Machine Air Leg Jack Hammer Portable Pneumatic Rock Drill 7



YT29 YT28 YT27 Rock Drilling Machine Air Leg Jack Hammer Portable Pneumatic Rock Drill 8

YT29 YT28 YT27 Rock Drilling Machine Air Leg Jack Hammer Portable Pneumatic Rock Drill 9



YT29 YT28 YT27 Rock Drilling Machine Air Leg Jack Hammer Portable Pneumatic Rock Drill 10



Products Description

Product name: Pneumatic Rock Drill
Name: Air Leg Rock Drill
Type:pneumatic jack hammer
Air pressure:0.4-0.63mpa
Cylinder Diameter:82mm
Rock drill depth:6m
Drilling Frequency:37HZ
Drilling Hole Dia.:35-45mm
Impact energy:>70J
Shank size:H22*108mm
Weight:29 KG
Dimension(L*W*H):659*248*205 mm
Application:mining ,concrete breaking,metallurgy, coal,railway
Feature:easy Operation,light weight, high drilling efficiency



YT29 YT28 YT27 Rock Drilling Machine Air Leg Jack Hammer Portable Pneumatic Rock Drill 11

YT29 YT28 YT27 Rock Drilling Machine Air Leg Jack Hammer Portable Pneumatic Rock Drill 12

YT29 YT28 YT27 Rock Drilling Machine Air Leg Jack Hammer Portable Pneumatic Rock Drill 13

YT29 YT28 YT27 Rock Drilling Machine Air Leg Jack Hammer Portable Pneumatic Rock Drill 14

YT29 YT28 YT27 Rock Drilling Machine Air Leg Jack Hammer Portable Pneumatic Rock Drill 15

YT29 YT28 YT27 Rock Drilling Machine Air Leg Jack Hammer Portable Pneumatic Rock Drill 16

YT29 YT28 YT27 Rock Drilling Machine Air Leg Jack Hammer Portable Pneumatic Rock Drill 17

YT29 YT28 YT27 Rock Drilling Machine Air Leg Jack Hammer Portable Pneumatic Rock Drill 18

Company Profile

YT29 YT28 YT27 Rock Drilling Machine Air Leg Jack Hammer Portable Pneumatic Rock Drill 19

YT29 YT28 YT27 Rock Drilling Machine Air Leg Jack Hammer Portable Pneumatic Rock Drill 20

YT29 YT28 YT27 Rock Drilling Machine Air Leg Jack Hammer Portable Pneumatic Rock Drill 21

YT29 YT28 YT27 Rock Drilling Machine Air Leg Jack Hammer Portable Pneumatic Rock Drill 22

1.What can you buy from us?

DTH drilling rig,Integrated DTH DTH drilling rig ,core drilling rig,highway pile driver,solar pile driver ,anchor pile driver,rotary drill rig ,Top Hammer drill rig,Underground jumbo drill rig ,DTH hammer,screw air compressor,screw air compressor,piston air compressor,pneumatic rock drill ,drill rod,drill bit,PDC drill bit,top hammer drill bit,tricone bit ,spare parts.



2.How can I make payment?

A:You can pay by credit card, TT, Western Union, LC etc.



3.How is the shipment? How long dose it take?

A: For large quantity or heavy products, we ship by sea shipping or land shipping. Shipping efficiency depends on country and city you want to ship to. For small and delicate products, we ship by DHL, UPS, Fedex or TNT. You can also appoint shipping method you like before we ship.


4.How is your quality control?
A: We have our own experienced QC. There will be strict inspection and testing for every order before shipping out.
