Screw Air Compressor Water Well Air Compressor Machine Portable Diesel Air Compressor

1Set/Sets per Month
MOQ
negotiable
Price
Screw Air Compressor Water Well Air Compressor Machine Portable Diesel Air Compressor
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Screw Air Compressor
Name: Air Compressor Machine, Portable Air Compressor
Power Source: Diesel
Diesel Engine: Cummins
Motor Power: 239kw
Air Consumption: 24m3/min
Working Pressure: 22bar
Application: Water Well Drilling,mining Blasting,General Industry,Air
Feature: High Drilling Efficiency,Hydraulic Controlling,Portable
Cooling Method: Air Or Water Cooled
Type: Screw Air Compressor
Warranty: 1 Year
Dimension(l*w*h): 3050*1850*2120mm
Weight: 3315KG
Configuration: Stationary
Condition: New
Highlight:

Portable Diesel Air Compressor

,

Screw Air Compressor Machine

,

Water Well Air Compressor Machine

Basic Infomation
Place of Origin: Zhejiang, China
Brand Name: SANROCK
Certification: CE ISO 9001:2015
Model Number: QSDS850CY-22
Payment & Shipping Terms
Packaging Details: Nude package for machines, Wooden box package for spare parts, Or customer demand.
Delivery Time: 15-30days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5000Set/Sets per Month
Product Description



Screw Air Compressor Water Well Air Compressor Machine Portable Diesel Air Compressor 0Screw Air Compressor Water Well Air Compressor Machine Portable Diesel Air Compressor 1

Screw Air Compressor Water Well Air Compressor Machine Portable Diesel Air Compressor 2

Screw Air Compressor Water Well Air Compressor Machine Portable Diesel Air Compressor 3



Screw Air Compressor Water Well Air Compressor Machine Portable Diesel Air Compressor 4



1. The screw air compressor is designed for high efficiency and high performance. It utilizes screw technology to deliver a high volume of compressed air with minimal energy consumption.

2. It can handle heavy-duty tasks and provide a continuous supply of compressed air, allowing for seamless operation in demanding environments.

3. The is equipped with an control system that offers precise control over the compressor's operation. The control system enables accurate monitoring of pressure levels, temperature, and other parameters. 4. The is designed for easy maintenance and serviceability. It features accessible maintenance points and user-friendly components, simplifying routine inspections, oil changes, and filter replacements.

Screw Air Compressor Water Well Air Compressor Machine Portable Diesel Air Compressor 5Screw Air Compressor Water Well Air Compressor Machine Portable Diesel Air Compressor 6

Screw Air Compressor Water Well Air Compressor Machine Portable Diesel Air Compressor 7

Products Description

Product name
Screw air compressor
Brand Name
Sanrock
Model Number
QSDS850CY-22
F.A.D m3/min/CFM
24/850
Pressure bar/PSI
22/320
Lubricating capacity(L)
110
Air end
Two stage compression
Diesel engine
Cummins 239kw
2200rpm
Fuel tank capacity(L)
376
Outlet valve
G1 1/2x1 & G2x1
Structure form
Stationary (2/4 wheels optional)
Weight(kg)
3315
Dimension(mm)
3050*1850*2120mm



Screw Air Compressor Water Well Air Compressor Machine Portable Diesel Air Compressor 8

Screw Air Compressor Water Well Air Compressor Machine Portable Diesel Air Compressor 9

Screw Air Compressor Water Well Air Compressor Machine Portable Diesel Air Compressor 10

Screw Air Compressor Water Well Air Compressor Machine Portable Diesel Air Compressor 11

Screw Air Compressor Water Well Air Compressor Machine Portable Diesel Air Compressor 12Screw Air Compressor Water Well Air Compressor Machine Portable Diesel Air Compressor 13

Screw Air Compressor Water Well Air Compressor Machine Portable Diesel Air Compressor 14

Screw Air Compressor Water Well Air Compressor Machine Portable Diesel Air Compressor 15Screw Air Compressor Water Well Air Compressor Machine Portable Diesel Air Compressor 16

Company Profile
Screw Air Compressor Water Well Air Compressor Machine Portable Diesel Air Compressor 17


Screw Air Compressor Water Well Air Compressor Machine Portable Diesel Air Compressor 18

Screw Air Compressor Water Well Air Compressor Machine Portable Diesel Air Compressor 19

Screw Air Compressor Water Well Air Compressor Machine Portable Diesel Air Compressor 20

1.What can you buy from us?

DTH drilling rig,core drilling rig,highway pile driver,solar pile driver ,anchor pile driver,rotary drill rig ,Top Hammer drill rig,underground jumbo drill rig ,hydraulic scaling rig,DTH hammer,drill rod,screw air compressor,water well drilling rig,truck mounted water well drilling rig,reverse circulation drilling rig,environmental drilling rig,screw air compressor,piston air compressor,pneumatic rock drill ,drill bit,tricone bit ,spare parts.



2.How can I make payment?

A:You can pay by credit card, TT, Western Union, LC etc.



3. How is the shipment? How long dose it take?

A: For large quantity or heavy products, we ship by sea shipping or land shipping. Shipping efficiency depends on country and city you want to ship to. For small and delicate products, we ship by DHL, UPS, Fedex or TNT.You can also appoint shipping method you like before we ship.



4.How is your quality control?

A: We have our own experienced QC.There will be strict inspection and testing for every order before shipping out.
