Water Well 24m3/min Diesel Screw Mobile Air Compressor with Air or Water Cooling

1Set/Sets per Month
MOQ
negotiable
Price
Water Well 24m3/min Diesel Screw Mobile Air Compressor with Air or Water Cooling
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Screw Air Compressor
Name: Air Compressor Machine, Portable Air Compressor
Power Source: Diesel
Diesel Engine: Cummins
Motor Power: 239kw
Air Consumption: 24m3/min
Working Pressure: 22bar
Application: Water Well Drilling,mining Blasting,General Industry,Air
Feature: High Drilling Efficiency,Hydraulic Controlling,Portable
Cooling Method: Air Or Water Cooled
Type: Screw Air Compressor
Warranty: 1 Year
Dimension(l*w*h): 3050*1850*2120mm
Weight: 3315KG
Configuration: Stationary
Condition: New
Highlight:

24m3/min Screw Air Compressor

,

Water Well Screw Air Compressor

,

Water Cooling Diesel Screw Air Compressor

Basic Infomation
Place of Origin: Zhejiang, China
Brand Name: SANROCK
Certification: CE ISO 9001:2015
Model Number: QSDS850CY-22
Payment & Shipping Terms
Packaging Details: Nude package for machines, Wooden box package for spare parts, Or customer demand.
Delivery Time: 15-30days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5000Set/Sets per Month
Product Description

Water Well 24m3/min Diesel Screw Mobile Air Compressor with Air or Water Cooling 0Water Well 24m3/min Diesel Screw Mobile Air Compressor with Air or Water Cooling 1

Water Well 24m3/min Diesel Screw Mobile Air Compressor with Air or Water Cooling 2

1. The screw air compressor is designed for high efficiency and high performance. It utilizes screw technology to deliver a high volume of compressed air with minimal energy consumption.

2. It can handle heavy-duty tasks and provide a continuous supply of compressed air, allowing for seamless operation in demanding environments.

3. The is equipped with an control system that offers precise control over the compressor's operation. The control system enables accurate monitoring of pressure levels, temperature, and other parameters. 4. The is designed for easy maintenance and serviceability. It features accessible maintenance points and user-friendly components, simplifying routine inspections, oil changes, and filter replacements.

Water Well 24m3/min Diesel Screw Mobile Air Compressor with Air or Water Cooling 3Water Well 24m3/min Diesel Screw Mobile Air Compressor with Air or Water Cooling 4

Water Well 24m3/min Diesel Screw Mobile Air Compressor with Air or Water Cooling 5



Water Well 24m3/min Diesel Screw Mobile Air Compressor with Air or Water Cooling 6Water Well 24m3/min Diesel Screw Mobile Air Compressor with Air or Water Cooling 7Water Well 24m3/min Diesel Screw Mobile Air Compressor with Air or Water Cooling 8





Products Description

Product name
Screw air compressor
Brand Name
Sanrock
Model Number
QSDS850CY-22
F.A.D m3/min/CFM
24/850
Pressure bar/PSI
22/320
Lubricating capacity(L)
110
Air end
Two stage compression
Diesel engine
Cummins 239kw
2200rpm
Fuel tank capacity(L)
376
Outlet valve
G1 1/2x1 & G2x1
Structure form
Stationary (2/4 wheels optional)
Weight(kg)
3315
Dimension(mm)
3050*1850*2120mm



Water Well 24m3/min Diesel Screw Mobile Air Compressor with Air or Water Cooling 9

Water Well 24m3/min Diesel Screw Mobile Air Compressor with Air or Water Cooling 10

Water Well 24m3/min Diesel Screw Mobile Air Compressor with Air or Water Cooling 11

Water Well 24m3/min Diesel Screw Mobile Air Compressor with Air or Water Cooling 12

Water Well 24m3/min Diesel Screw Mobile Air Compressor with Air or Water Cooling 13Water Well 24m3/min Diesel Screw Mobile Air Compressor with Air or Water Cooling 14

Water Well 24m3/min Diesel Screw Mobile Air Compressor with Air or Water Cooling 15

Water Well 24m3/min Diesel Screw Mobile Air Compressor with Air or Water Cooling 16Water Well 24m3/min Diesel Screw Mobile Air Compressor with Air or Water Cooling 17

Company Profile
Water Well 24m3/min Diesel Screw Mobile Air Compressor with Air or Water Cooling 18


Water Well 24m3/min Diesel Screw Mobile Air Compressor with Air or Water Cooling 19

Water Well 24m3/min Diesel Screw Mobile Air Compressor with Air or Water Cooling 20

Water Well 24m3/min Diesel Screw Mobile Air Compressor with Air or Water Cooling 21

1.What can you buy from us?

DTH drilling rig,core drilling rig,highway pile driver,solar pile driver ,anchor pile driver,rotary drill rig ,Top Hammer drill rig,underground jumbo drill rig ,hydraulic scaling rig,DTH hammer,drill rod,screw air compressor,water well drilling rig,truck mounted water well drilling rig,reverse circulation drilling rig,environmental drilling rig,screw air compressor,piston air compressor,pneumatic rock drill ,drill bit,tricone bit ,spare parts.



2.How can I make payment?

A:You can pay by credit card, TT, Western Union, LC etc.



3. How is the shipment? How long dose it take?

A: For large quantity or heavy products, we ship by sea shipping or land shipping. Shipping efficiency depends on country and city you want to ship to. For small and delicate products, we ship by DHL, UPS, Fedex or TNT.You can also appoint shipping method you like before we ship.



4.How is your quality control?

A: We have our own experienced QC.There will be strict inspection and testing for every order before shipping out.
