Portable Rock Drilling Machine with Length 575mm Pneumatic Rock Drill Concrete Creaker Air Pick Hammer

1Set/Sets per Month
MOQ
negotiable
Price
Portable Rock Drilling Machine with Length 575mm Pneumatic Rock Drill Concrete Creaker Air Pick Hammer
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Pneumatic Rock Drill
Application: Mining, Road Construction,concrete Breaking
Average Air Consumption: ≤27 L/S
Length: 575mm
Working Pressure: 0.50-0.63 Mpa
Impact Frequency: ≥16 Hz
Keyword: Air Breaker Hammer
Feature: High Drilling Efficiency,Hydraulic Controlling,Portable
Single Package Size: 80X30X30 Cm
Single Gross Weight: 17kg
Highlight:

Portable Rock Drilling Machine

,

Length 575mm Pneumatic Rock Drill

,

Concrete Creaker Air Pick Hammer

Basic Infomation
Place of Origin: Zhejiang, China
Brand Name: SANROCK
Certification: CE ISO 9001:2015
Model Number: G15
Payment & Shipping Terms
Packaging Details: Nude package for machines, Wooden box package for spare parts, Or customer demand.
Delivery Time: 10-18days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5000Set/Sets per Month
Product Description

Portable Rock Drilling Machine with Length 575mm Pneumatic Rock Drill Concrete Creaker Air Pick Hammer 0

Portable Rock Drilling Machine with Length 575mm Pneumatic Rock Drill Concrete Creaker Air Pick Hammer 1

Portable Rock Drilling Machine with Length 575mm Pneumatic Rock Drill Concrete Creaker Air Pick Hammer 2

It can be widely used for reinforced concrete breaking or removing, such as the construction building part demolition, bridge dismantling, demolishing underwater etc.
This air pick hammer is tools with compressed air as its power. The compressed air is distributed alternatively through the distributing valve into either end of the cylinder assembly . The hammer inside is made to carry on a reciprocaql motion which impacts the shank of the steel chisel by the tappet .



Portable Rock Drilling Machine with Length 575mm Pneumatic Rock Drill Concrete Creaker Air Pick Hammer 3

Portable Rock Drilling Machine with Length 575mm Pneumatic Rock Drill Concrete Creaker Air Pick Hammer 4

Feature:

Specific performance is as follows:

1. Easily-accessible position throttle .

2. Integral muffler,lower noise .

3. It accepts heavy duty bits .

4. Reliable structure,easy and stable operation .

5. Drill diam. can be from 32mm-60mm.

6. Hand-held and air legs rock drill accessible.

7. Provide the ultimate combination of performance and economy.



Products Description

Brand Name:Sanrock
Model Number:G15
Product name:Pneumatic rock drill
Type:Air hammer
Working Pressure:0.5-0.63Mpa
Average Air Consumption:≤27 L/S
Piston stroke:60mm
Piston diameter:80mm
Shank size:H22*108
Maximum Torque:Adjustable
Application:Quarry, mining, construction,concrete breaking



Portable Rock Drilling Machine with Length 575mm Pneumatic Rock Drill Concrete Creaker Air Pick Hammer 5Portable Rock Drilling Machine with Length 575mm Pneumatic Rock Drill Concrete Creaker Air Pick Hammer 6Portable Rock Drilling Machine with Length 575mm Pneumatic Rock Drill Concrete Creaker Air Pick Hammer 7







Portable Rock Drilling Machine with Length 575mm Pneumatic Rock Drill Concrete Creaker Air Pick Hammer 8Portable Rock Drilling Machine with Length 575mm Pneumatic Rock Drill Concrete Creaker Air Pick Hammer 9

Portable Rock Drilling Machine with Length 575mm Pneumatic Rock Drill Concrete Creaker Air Pick Hammer 10

Portable Rock Drilling Machine with Length 575mm Pneumatic Rock Drill Concrete Creaker Air Pick Hammer 11

Portable Rock Drilling Machine with Length 575mm Pneumatic Rock Drill Concrete Creaker Air Pick Hammer 12

Portable Rock Drilling Machine with Length 575mm Pneumatic Rock Drill Concrete Creaker Air Pick Hammer 13Portable Rock Drilling Machine with Length 575mm Pneumatic Rock Drill Concrete Creaker Air Pick Hammer 14Portable Rock Drilling Machine with Length 575mm Pneumatic Rock Drill Concrete Creaker Air Pick Hammer 15

Company Introduction

Portable Rock Drilling Machine with Length 575mm Pneumatic Rock Drill Concrete Creaker Air Pick Hammer 16



Portable Rock Drilling Machine with Length 575mm Pneumatic Rock Drill Concrete Creaker Air Pick Hammer 17

Portable Rock Drilling Machine with Length 575mm Pneumatic Rock Drill Concrete Creaker Air Pick Hammer 18



Portable Rock Drilling Machine with Length 575mm Pneumatic Rock Drill Concrete Creaker Air Pick Hammer 19

1.What can you buy from us?

DTH drilling rig,Integrated DTH DTH drilling rig ,core drilling rig,highway pile driver,solar pile driver ,anchor pile driver,rotary drill rig ,Top Hammer drill rig,Underground jumbo drill rig ,DTH hammer,screw air compressor,screw air compressor,piston air compressor,pneumatic rock drill ,drill rod,drill bit,PDC drill bit,top hammer drill bit,tricone bit ,spare parts.



2.How can I make payment?

A:You can pay by credit card, TT, Western Union, LC etc.



3.How is the shipment? How long dose it take?

A: For large quantity or heavy products, we ship by sea shipping or land shipping. Shipping efficiency depends on country and city you want to ship to. For small and delicate products, we ship by DHL, UPS, Fedex or TNT. You can also appoint shipping method you like before we ship.



4.How is your quality control?
A: We have our own experienced QC. There will be strict inspection and testing for every order before shipping out.
