Home /Products/Crawler Water Well Drilling Rig/Customized Hydraulic Controlling Water Well Drilling Machine with 1.5m Drill Pipe Length

Customized Hydraulic Controlling Water Well Drilling Machine with 1.5m Drill Pipe Length

1Set/Sets per Month
MOQ
negotiable
Price
Customized Hydraulic Controlling Water Well Drilling Machine with 1.5m Drill Pipe Length
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Water Well Drilling Rig
Name: Water Well Drilling Rig Machine,Crawler Water Well Drilling Rig
Engine: Diesel Engine
Power Type: Diesel
Power(w): 60KW
Drilling Depth: 180m
Drilling Diameter: 140-254mm
Swing Torque: 3200-4600N.m
Air Consumption: 17-31m3/min
Drill Pipe Diameter: 76mm / 89mm
Drill Pipe Length: 1.5m, 2.0m, 3.0m
Application: Water Well Drilling Rig Mobile Drilling Rig,drilling Well
Feature: Hydraulic Controlling,Light Weight High Drilling Efficiency
Usage: Water Well
Type: Rotary Drilling Rig
Warranty: 12 Months
Dimension(l*w*h): 4000×1630×2250mm
Weight: 5200KG
Highlight:

Customized Water Well Drilling Machine

,

Hydraulic Controlling Water Well Drilling Machine
Basic Infomation
Place of Origin: Zhejiang, China
Brand Name: SANROCK
Certification: CE ISO 9001:2015
Model Number: SR180 Rubber Crawler Base
Payment & Shipping Terms
Packaging Details: Nude package for machines, Wooden box package for spare parts, Or customer demand.
Delivery Time: 15-30days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5000Set/Sets per Month
Product Description



Customized Hydraulic Controlling Water Well Drilling Machine with 1.5m Drill Pipe Length 0
Customized Hydraulic Controlling Water Well Drilling Machine with 1.5m Drill Pipe Length 1
Extensively applicable to drilling water wells, agricultural irrigation wells, geothermal air-conditioning wells and well holes of other purposes, especially applicable to water intake projects in mountain regions and at rock stratums.
Feature:
1.SR180 series deep(water) well-drilling rig uses full hydraulic control, and the Top drive to drive the rotation of drilling tools with very high drilling efficiency.
2.Water Well Crawler Drilling Rig is a light, highly-efficient and multifunction drilling device,convenient use, reliability and durability.
3.Each hydraulic tubing is covered with a protective shell to effectively extend the service life of pipeline.
4.Lifting force: composite arm with small size yet long stroke, double cylinder lifting, strong lifting capacity
5.Hydraulic oil pump: It uses parallel gearbox to separate oil pump monomer, supply adequate power and distribute reasonable. The hydraulic system adopts unique design, which is easy to maintain and can lower the maintenance cost. 6.Rotary head device: integrated casting gearbox , dual motor power, large torque, durable, small maintenance costs.
Customized Hydraulic Controlling Water Well Drilling Machine with 1.5m Drill Pipe Length 2Customized Hydraulic Controlling Water Well Drilling Machine with 1.5m Drill Pipe Length 3
Customized Hydraulic Controlling Water Well Drilling Machine with 1.5m Drill Pipe Length 4Customized Hydraulic Controlling Water Well Drilling Machine with 1.5m Drill Pipe Length 5

Customized Hydraulic Controlling Water Well Drilling Machine with 1.5m Drill Pipe Length 6

Products Description

Product Name:SR180 hydraulic water well drilling rig
Drilling Depth:180m
The hole diameter:140-254mm
Equipped capacitor:60KW
Using air pressure:1.7-2.5MPA
Air consumption:17-31m3/min
Swing speed:45-70rpm
Climbing angles:30Max
Walking speed:2.5km/h
Swing torque:3200-4600N.m
The engine brand:Yuchai engine
Equipped with hammer:Medium and high wind pressure series
The penetration efficiency:10-35m/h
Drill pipe diameter:76mm / 89mm
Drill pipe length:1.5m / 2.0m / 3.0m
Dimension:4000×1630×2250mm
The weight:5200KG


Customized Hydraulic Controlling Water Well Drilling Machine with 1.5m Drill Pipe Length 7

Customized Hydraulic Controlling Water Well Drilling Machine with 1.5m Drill Pipe Length 8

Customized Hydraulic Controlling Water Well Drilling Machine with 1.5m Drill Pipe Length 9Customized Hydraulic Controlling Water Well Drilling Machine with 1.5m Drill Pipe Length 10

Customized Hydraulic Controlling Water Well Drilling Machine with 1.5m Drill Pipe Length 11

Customized Hydraulic Controlling Water Well Drilling Machine with 1.5m Drill Pipe Length 12

Customized Hydraulic Controlling Water Well Drilling Machine with 1.5m Drill Pipe Length 13

Customized Hydraulic Controlling Water Well Drilling Machine with 1.5m Drill Pipe Length 14

Customized Hydraulic Controlling Water Well Drilling Machine with 1.5m Drill Pipe Length 15Customized Hydraulic Controlling Water Well Drilling Machine with 1.5m Drill Pipe Length 16

Company Profile

Customized Hydraulic Controlling Water Well Drilling Machine with 1.5m Drill Pipe Length 17Customized Hydraulic Controlling Water Well Drilling Machine with 1.5m Drill Pipe Length 18



Customized Hydraulic Controlling Water Well Drilling Machine with 1.5m Drill Pipe Length 19

Customized Hydraulic Controlling Water Well Drilling Machine with 1.5m Drill Pipe Length 20

1.What can you buy from us?
DTH drilling rig,Integrated DTH DTH drilling rig ,core drilling rig,highway pile driver,solar pile driver ,anchor pile driver,rotary drill rig ,Top Hammer drill rig,Underground jumbo drill rig ,DTH hammer,drill rod,screw air compressor,screw air compressor,piston air compressor,pneumatic rock drill ,drill bit,PDC drill bit,top hammer drill bit,tricone bit ,spare parts.



2.How can I make payment?
A:You can pay by credit card, TT, Western Union, LC etc.



3. How is the shipment? How long dose it take?
A: For large quantity or heavy products, we ship by sea shipping or land shipping. Shipping efficiency depends on country and city you want to ship to. For small and delicate products, we ship by DHL, UPS, Fedex or TNT.You can also appoint shipping method you like before we ship.



4.How is your quality control?
A: We have our own experienced QC.There will be strict inspection and testing for every order before shipping out.
